CMM INSPECTION SERVICE IN CHENNAI A coordinate measuring machine (CMM) is a device that measures the geometry of physical objects by sensing discrete points on the surface of the object with a probe. Various types of probes are used in CMMs, including mechanical, optical, laser, and white light. Depending on the machine, the probe position may be manually controlled by an operator or it may be computer controlled. CMMs typically specify a probe's position in terms of its displacement from a reference position in a three-dimensional Cartesian coordinate system (i.e., with XYZ axes). In addition to moving the probe along the X, Y, and Z axes, many machines also allow the probe angle to be controlled to allow measurement of surfaces that would otherwise be unreachable.
update image not found
LASER TRACKER INSPECTION SERVICE. FARO LASER TRACKER Laser trackers are instruments that accurately measure large objects by determining the positions of optical targets held against those objects. The accuracy of laser trackers is of the order of 0.025 mm over a distance of several metres.[1] Some examples of laser tracker applications are to align aircraft wings during assembly[2] and to align large machine tools.[3] To take measurements the technician first sets up a laser tracker on a tripod with an unobstructed view of the object to be measured. The technician removes a target from the base of the laser tracker and carries it to the object to be measured, moving smoothly to allow the laser tracker to follow the movement of the target. The technician places the target against the object and triggers measurements to be taken at selected points, sometimes by a remote control device. Measurements can be imported into different types of software to plot the points or to calculate deviation from the correct position.[4] The targets are known as "retroreflective" because they reflect the laser beam back in the same direction it came from (in this case, back to the laser tracker). One type of target in common use is called a spherically mounted retroreflector (SMR), [5] which resembles a ball bearing with mirrored surfaces cut into it.[6]
update image not found
Laser and Ball Bar Calibration for CNC Machines Service in Chennai and Coimbatore: UNIQUE MEASUREMENT SERVICE (9965251951 & 7358051091)
update image not found
Video Measuring System Measurement Service in Chennai and Coimbatore: UNIQUE MEASUREMENT SERVICE (9965251951 & 7358051091)
update image not found
Portable Surface Roughness Testing Service in Chennai and Coimbatore: UNIQUE MEASUREMENT SERVICE (9965251951 & 7358051091)
